General-Purpose Oscilloscopes

RIGOL DS1000-Series Digital Oscilloscopes offer exceptional waveform viewing
and measurements in a compact, lightweight package. The DS1000 series are ideal
for production test, field service, research and design and all of the applications
involving analog/digital circuits test and troubleshooting, as well as education and
training.
Each of these oscilloscopes gives you:
Dual Channel, Bandwidth:
100MHz (DS1102CD, DS1102C, DS1102MD, DS1102M)
60MHz (DS1062CD, DS1062C, DS1062MD, DS1062M)
40MHz (DS1042CD, DS1042C, DS1042MD, DS1042M)
25MHz (DS1022CD, DS1022C, DS1022MD, DS1022M)
Optional 16 digital channels (Mixed signal oscilloscope), each channel can be
turned on or off independently, or in a 8 bit group
Mono/Color TFT LCD Displays at 320*234 resolution
USB storage and printing supports, firmware upgradeable via USB connectivity
Adjustable waveform intensity, more effective waveform viewing
One-touch automatic setup for ease of use (AUTO)
Saves 10 Waveforms, 10 setups, supports CSV and bitmap format
Newly designed Delayed Scan Function, easy to give attention to both details
and overview of a waveform
20 Automatic measurements
Automatic cursor tracking measurements
Waveform recorder, record and replay dynamic waveforms
User selectable fast offset calibration
Built-in FFT function, Frequency Counter
Digital filters, includes LPF, HPF, BPF, BRF
Pass/Fail Function, optically isolated Pass/Fail output
Add, Subtract and Multiply Mathematic Functions
Advanced trigger types include: Edge, Video, Pulse width, Slope, Alternative,
Pattern and Duration (Mixed signal oscilloscope)
Adjustable trigger sensitivity
