INSERTS
Pressing the INSERTS key displays the inserts knob set for editing plug-ins. In
normal mode, the first plug-in is displayed on the knob. Pressing one of these
Knob Tops in normal mode toggles the MC Mix into channel mode and displays
the first eight plug-in parameters for editing. Pressing a plug-in's Knob Top
displays its parameters for editing.
EQ
Press the EQ key to display the EQ knob set to configure equalization controls
and filters. This automatically toggles the MC into channel mode and shows four
EQ bands on eight knobs.
AUX
Press the AUX key to display the Aux knob set to control auxiliary sends. In normal
mode, the first aux send is displayed. In normal mode, press the PAGE
advance to the second aux send. In channel mode, up to eight aux sends can be
shown at once.
PAN
36
Press the PAN key to display the Pan knob set to configure left/right or surround
panning. In normal mode, the left/right pan control is typically displayed. In
channel mode, the first page of eight pan knobs is shown.
INPUT
Press the
gains, phantom power, and other application-specific parameters.
DYN
Press the
limiters, expanders, and gates.
GROUP
Press the
or control group (VCA) membership.
MIX
Press the
INPUT
key to display the Input knob set to configure input routing, mic
DYN key to display the Dynamics knob set to configure compressors,
GROUP key to display the Group knob set to configure group bus routing
MIX key to display the Mix knob set to configure output routing.
