5.4.1

MC Mix display screen dim time

Drag the slider to set the amount of inactive time before the MC Mix display
screens dims to half intensity.
5.4.2

Footswitch

The footswitch punches in and out of recording. It is useful when recording and
getting ready to play an instrument.
Two types of footswitches can be attached to an MC Mix:
• Momentary – There are two momentary types: normally open, push to close;
normally closed, push to open.
• Toggle – Latches when pushed on; push again for off.
We recommend using one of the momentary types. The toggle type works, but
requires two presses. The MC Mix automatically distinguishes between momen-
tary types by checking whether the switch is open or closed upon power up.

Operation

This category selects what happens when the footswitch is pressed. Choose the
option that best suits your application.
Record | Record: Pressing the footswitch presses the RECORD button, which
punches in to record. Releasing the footswitch does nothing. Pressing the foot-
switch again also presses the RECORD button, which punches out.
Record | Play: Pressing the footswitch the first time presses the RECORD button,
which punches in. Releasing it does nothing. Pressing it a second time presses
the PLAY button, which punches out of recording and continues playback.
Status
This field cannot be set but shows the current status of the footswitch (on/off)
and its polarity.
5.4.3

MC Control Display

Drag the Brightness slider to adjust the MC Control Touchscreen display. Note
that this control is gray and inactive if an MC Control is not connected to your
instance of EuControl.
