Inserts
1. Add a plug-in on track 1 of your application.
2. If tracks 1–8 are not assigned to strips 1–8, press the
to restore tracks 1–8 to strips 1–8.
3. Press the MC Mix's strip 1 fader SEL key (Figure 3-4).
4. Press the CHAN key to enter channel mode (Figure 3-4).
CHAN
key
INSERTS
key
5. Press the INSERTS key (Figure 3-4).
The names of the plug-ins on that track spill across the display screens.
6. Press the Soft Knob (Figure 3-4) below the desired plug-in's name to select it.
The Soft Knobs can be turned like a conventional knob and pressed like a
switch to access an additional function.
The parameters of that plug-in spill across the display screens.
7. Turn the Soft Knob below the desired parameter to adjust its value.
SEL
TOP
BACK
ON
CFG CFG
PAGE PAGE
FLIP
CHAN
INPUT
INSERTS
DYN
EQ
GROUP
AUX
Figure 3-4 Fader strip, INSERTS and CHAN keys
Artist Series
HOME
Soft
Knob
SOLO ON
12
6
0
fader
5
SEL key
10
key (Figure 3-2)
