EP-6VBA
On the basis of bounded functions in I/O chipset, the two serial ports are able to
support the External Modem Ring-in Power ON function. Once users connect
the external modem to COM1 or COM2, the EP-6VBA mainboard allows users
to turn on their system through the remote and host's dial-up control.
Exclusive Keyboard Power ON Function
To innovate a unique feature to benefit users, we devoted the easiest and most
convenient way to turn on your system based on the the ATX power supply.
How to work with it
Step 1: Please check JP4 at the position 2-3 after you finished the system
installation.
J P 4
Step 2: You can enjoy the Keyboard Power ON function (KBPO) by pressing
any 2 key and BUTTON only to turn on your system. Your system will
be turned on automatically, after releasing the keys. To power off you
system, you can use the Soft-OFF function under Windows 95.
Notes: Intel ATX version 2.0 specification has recommended you use the
power supply with 0.72A(720mA) in 5.0VSB. With our EP-6VBA
mainboard, the 5.0VSB standby power only has to be > = 0.2A (200mA)
then you can enjoy this unique benefit. However, the ATX power
supply which is < 0.2 (200mA) is still applicable to your system by
placed JP4 at the position 1-2 to disable this feature.
K eybo a rd P ow er-O N F un ctio n Se le ctio n
1 -2 : D isab led
(D efau lt)
2 -3 : E n ab led
Installation
Page 3-11
