EP-6VBA
The "LOAD SETUP DEFAULTS" function loads the system default data directly
from ROM and initializes the associated hardware properly. This function will be
necessary only when the system CMOS data is corrupted.
OnChip IDE Channel0
OnChip IDE Channel1

IDE Prefetch Mode

Primary Master PIO
Primary Slave
PIO
Secondary Master PIO
Secondary Slave PIO
Primary Master UDMA
Primary Slave UDMA
Secondary MasterUDMA
Secondary Slave UDMA
Init Display First
Onboard FDD Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART 2 Mode
IR Function Duplex
TX, RX inverting enable
Note: If you do not use the Onboard IDE connector, then you will need to
set Onboard Primary PCI IDE: Disabled and Onboard Secondary
PCI IDE: Disabled
Note: The Onboard PCI IDE cable should be equal to or less than 18
inches (45 cm.).
IDE Prefetch Mode:
Enable prefetching for IDE drive interfaces that support its faster drive
accesses. If uou are getting disk drive errors, change the setting to omit the
drive interface where the errors occur. Depending on the configuration of your
IDE subsystem, this field may not appear, and it does not appear when the
Internal PCI/IDE field, above, is Disabled.
The Choice: Enabled, Disabled.
ROM PCI/ISA BIOS(2A6LGPAA)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
: Enabled
Onboard Parallel Port
: Enabled
Onboard Parallel Mode
: Enabled
ECP Mode Use DMA
: Auto
Parallel Port EPP Type
: Auto
Onboard Legacy Audio
: Auto
Sound Blaster
: Auto
SB I/O Base Address
: Auto
SB IRQ Select
: Auto
SB DMA Select
: Auto
MPU-401
: Auto
MPU-401 I/O Address
: PCI Slot
FM Port (388-38BH)
Game Port (200-207H)
: Enabled
: Auto
Esc : Quit
: Auto
F1 : Help
: HPSIR
F5 : Old Values
: Half
F7 : Load Setup Defaults
: No, Yes
Figure 8: Integrated Peripherals
BIOS
: 378/IRQ7
: ECP/EPP
: 3
: EPP1.9
: Enabled
: Disabled
: 220H
: IRQ 5
: DMA 1
: Disabled
: 330-333H
: Disabled
: Enabled
: Select Item
PU/PD/+/- : Modify
(Shift) F2
: Color
Page 4-17
