Installation
(This is connected to the power button on the case. Using the
Soft-Off by Pwr-BTTN feature, you can choose either Instant
Off (turns system off immediatly), or 4 sec delay (you need to
hold the button down for 4 seconds before the system turns off).
When the system is in 4 sec delay mode, there is a special
feature to make the system to go into suspend mode when the
button is pressed momentarily.)
Power On/Off
J3
1
Turbo LED indicator - LED ON when higher speed is selected
+
IDE LED indicator - LED ON when Onboard PCI IDE Hard
+
disks is activate
IR Connector
1
J2
Power LED - Power LED connector
1
Speaker - Connect to the system's speaker for beeping
1
Reset - Closed to restart system.
1
Page 3-10
1. VCC
2. NC
3. IRRX
1. Power LED(+)
2. N/C
3. GND
1. Speaker
2. N/C
4. GND
5. IRTX
4. NC
5. GND
3. GND
4. GND
EP-6VBA
