TIMER MAP:
TIMER Channel 0
TIMER Channel 1
TIMER Channel 2
DMA CHANNELS:
DMA Channel 0
DMA Channel 1
DMA Channel 2
DMA Channel 3
DMA Channel 4
DMA Channel 5
DMA Channel 6
DMA Channel 7
NMI :
Parity check error.
IRQ (H/W):
0
System TIMER interrupt from TIMER 0.
1
KEYBOARD output buffer full.
2
Cascade for IRQ 8-15.
3
SERIAL port 2.
4
SERIAL port 1.
5
PARALLEL port 2.
6
FLOPPY DISK (SMC CHIP).
7
PARALLEL port 1.
8
RTC clock.
9
Available.
10
Available.
11
Available.
A-2
MONOCHROME & PARALLEL port adapter.
EGA adapter.
CGA adapter.
FLOPPY DISK controller.
SERIAL port 1.
System timer interrupt.
DRAM REFRESH request.
SPEAKER tone generator.
Available.
Onboard ECP (Option).
FLOPPY DISK (SMC CHIP).
Onboard ECP (default).
Cascade for DMA controller 1.
Available.
Available.
Available
