BIOS
Onchip IDE Channel:
The default value is Enabled.
Enabled: Enables Onboard IDE primary port.
Disabled: Disables Onboard IDE primary port.
Onchip IDE Channel:
The default is Enabled.
Enabled: Enables Onboard IDE secondary port.
Disabled: Disables Onboard IDE secondary port.
Primary Master PIO:
The default is Auto.
Auto: BIOS will automatically detect the Onboard Primary Master PCI IDE
HDD Accessing mode.
Mode 0~4:Manually set the IDE Programmed interrupt mode.
Primary Slave PIO:
The default is Auto.
Auto: BIOS will automatically detect the Onboard Primary Slave PCI
IDE HDD Accessing mode.
Mode 0~4: Manually set the IDE Programmed interrupt mode.
Secondary Master PIO:
The default is Auto.
Auto: BIOS will automatically detect the Onboard Secondary Master
PCI IDE HDD Accessing mode.
Mode 0~4: Manually set the IDE Programmed interrupt mode.
Secondary Slave PIO:
The default is Auto.
Auto: BIOS will automatically detect the Onboard Secondary Slave PCI IDE
HDD Accessing mode.
Mode 0~4: Manually set the IDE Programmed interrupt mode.
Primary Master UDMA:
This allows you to select the mode of operation for the hard drive.
The default is Auto.
Auto: The computer will select the optimal setting.
Disabled: The hard drive will run in normal mode.
Page 4-18
EP-6VBA
