Table 13. J11 SocketModem Power (3 V DC/5 V DC)
Shunt Position
IN (pins 1-2)
OUT (pins 2-3)
Table 14. J12–RS-485_1_Enable First Interface
Shunt Position
IN
OUT
Table 15. J13–RS-485_1_Enable Second Interface
Shunt Position
IN
OUT
Table 16. J14–RT_1, Termination Resistors Enable, RS-485 First Interface
Shunt Position
IN
OUT
UM014605-0208
®
Z8 Encore! Flash Microcontroller Development Kit
Function
5.0 V DC is provided to power
SocketModem
3.3 V DC is provided to power
SocketModem
Function
RS-485 disabled
Enables RS-485 first interface
Function
RS-485 disabled
Enables RS-485 second interface
Function
First RS-485 interface termination resistors
disabled
Enables first RS-485 interface termination
resistors
User Manual
Device Affected
SocketModem
SocketModem
Device Affected
none
Console and IrDA
Device Affected
none
SocketModem
Device Affected
none
