Table 5. Header J6 (Continued)
Pin No Signal Name Function
21 PE7
22 PA0
23 PE6
24 PA1
25 PE5
26 PA2
27 PE4
28 PA3
29 PE3
30 PA4
31 PE2
32 PA5
33 PE1
34 PA7
35 RESERVED
36 PA6
37
38
39 PD7
40 PC4
41 PD6
42 PC3
43 PD5
44 PC7
45 PD4
46 PC6
Note: Do not use pins marked Reserved when designing Expansion Modules.
All the signals are driven directly by the MCU.
UM014605-0208
®
Z8 Encore! Flash Microcontroller Development Kit
Port E, bit 7
Port A, bit 0
Port E, bit 6
Port A, bit1
Port E, bit 5
Port A, bit 2
Port E, bit 4
Port A, bit 3
Port E, bit 3
Port A, bit 4
Port E, bit 2
Port A, bit 5
Port E, bit 1
Port A, bit 7
Port A, bit 6
GND
GND
Port D, bit 7
Port C, bit 4
Port D, bit 6
Port C, bit 3
Port D, bit 5
Port C, bit 7
Port D, bit 4
Port C, bit 6
Direction Comments
IN/OUT
IN/OUT T0IN
IN/OUT
IN/OUT T0OUT
IN/OUT
IN/OUT
IN/OUT
IN/OUT CTS0
IN/OUT
IN/OUT RXD0
IN/OUT
IN/OUT TXD0
IN/OUT
IN/OUT SDA
IN/OUT SCL
IN/OUT RCOUT
IN/OUT MOSI
IN/OUT CTS1
IN/OUT MISO
IN/OUT TXD1
IN/OUT T2OUT
IN/OUT RXD1
IN/OUT T2IN
