Z8 Encore!

Introduction

Z8 Encore! evaluation board (64 KB version) is an evaluation and proto-
typing board for the Z8 Encore!
you with a tool to evaluate features of Z8 Encore! family, and to develop
an application before building the hardware.

Features

The features of the Z8 Encore! evaluation board include:
•
•
•
•
•
•
•
•
UM014605-0208
®
Z8 Encore!
®
Evaluation Board
Z8 Encore! MCU
LED array with four 7 x 5 LED matrices
Serial Communications Devices
2
– I C configuration IC for Expansion Module
– SPI Interface with temperature sensor
Infrared Data Association (IrDA) transceiver
Power and communication interfaces
– 9 V DC power supply
– Two RS-232 connectors
– One RS-485 connector with two ports
Expansion Module interface
Embedded modem socket with U.S. phone line interface (modem is
not included in the kit)
Three pushbuttons
Flash Microcontroller Development Kit
®
family of MCUs. The board provides
Z8 Encore!® Evaluation Board
User Manual
