ZiLOG UM014605-0208 User Manual page 25

Table 6. Header J8 (Continued)
Pin No Signal Name Function
7 PB4
8 PB5
9 PB6
10 PB7
11
12
13 PH0
14 PH1
15 PH2
16 PH3
17
18
19
20
21
22
23 PF0
24 PF1
25 PF2
26 PF3
27 PF4
28 PF5
29 PF6
30 PF7
31
32
Note: Do not use pins marked Reserved when designing Expansion Modules.
All the signals are driven directly by the MCU.
UM014605-0208
®
Z8 Encore! Flash Microcontroller Development Kit
Port B, bit 4
Port B, bit 5
Port B, bit 6
Port B, bit 7
GND
GND
Port H, bit 0
Port H, bit 1
Port H, bit 2
Port H, bit 3
GND
GND
Port F, bit 0
Port F, bit 1
Port F, bit 2
Port F, bit 3
Port F, bit 4
Port F, bit 5
Port F, bit 6
Port F, bit 7
VDD
VDD
Direction Comments
IN ALG4 Analog input
IN ALG5 Analog input
IN ALG6 Analog input
IN ALG7 Analog input
IN ALG8 Analog input
IN ALG9 Analog input
IN ALG10 Analog input
IN ALG11 Analog input
Reserved (see note)
Reserved (see note)
Reserved (see note)
Reserved (see note)
IN/OUT DTR1
IN/OUT RTS1
IN/OUT DSR1
IN/OUT DCD1
IN/OUT RI1
IN/OUT
IN/OUT
IN/OUT
Z8 Encore!® Evaluation Board
User Manual
21
