ZiLOG UM014605-0208 User Manual page 22

Table 5. Header J6
Pin No Signal Name Function
1
2
3
4
5 SCL
6 ID2
7 SDA
8 ID1
9
10 ID0
11 -MOD_DIS
12 -CON_DIS
13 -MWAIT
14 GND
15 PE0
16
17 -CS3
18
19 GND
20 GND
Note: Do not use pins marked Reserved when designing Expansion Modules.
All the signals are driven directly by the MCU.
UM014605-0208
®
Z8 Encore! Flash Microcontroller Development Kit
VCC
VCC
9 V DC
9 V DC
2
I C Clock
Evaluation Board
ID
2
I C Data
Evaluation Board
ID
GND
Evaluation Board
ID
Modem Disable
Console Disable
Port E, bit 0
Direction Comments
OUT
OUT
IN/OUT
OUT
OUT
OUT If a shunt is installed the Modem
Function on the evaluation
board is disabled
OUT If a shunt is installed the
Console Function on the
evaluation board is disabled
IN Reserved (see note)
IN/OUT
Reserved (see note)
Z8 Encore!® Evaluation Board
User Manual
18
