C H A P T E R 4
Using your interactive whiteboard system
Number Function
3 (Left), (Right),
(Up) and (Down) arrows
4 Hide
5 Mode
6 Mute
7
(Power)
8 (Enter)
9 (Volume Up)
10 (Volume Down)
N O T E
The Mute, Volume Up and Volume Down buttons work only if there is an audio source and
speaker system connected to the projector for the currently selected input source.

Adjusting projector settings

The remote control's Menu button enables you to access the on-screen display to adjust the projector
settings.
I M P O R T A N T
There are no projector menu options on the ACP. Keep your remote control in a safe place because
the ACP is not a substitute for the remote control.
Setting Use
Image Adjustment menu
Display Mode Indicates the projector's display output
(SMART Presentation,
Bright Room, Dark Room, sRGB
and User).
Brightness Adjusts projector brightness from 0 to
100.
Contrast Adjusts the difference between the
lightest and darkest parts
of the image from 0 to 100.
24
Description
Change the menu selections and adjustments.
Freeze, hide or display the image:
Press once to freeze the image.
l
For example, you can display a question on
the screen while you check your e-mail.
Press again to hide the image, that is, to
l
display a black screen.
Press again to return to the live image.
l
Select a display mode.
Mute audio amplification.
Turn on the projector or put it into Standby mode.
Accept the selected mode or option.
Increase audio amplification volume.
Decrease audio amplification volume.
Notes
The default is SMART Presentation.
The default is 50.
The default is 50.
