C H A P T E R 2
Installing your interactive whiteboard system
Connecting the components of your interactive
whiteboard system
This section lists all the components of your SMART Board 800ixe-SMP interactive whiteboard
system with appliance and explains how to connect them. Your interactive whiteboard system
includes the following components:
Interactive whiteboard
l
Projector
l
Appliance
l
ACP
l
CAT 5 USB extender
l
SMART GoWire cable
l
Your interactive whiteboard system is delivered with some cabling and connections completed. You
need to complete the following required connections:
Appliance to ACP
l
Appliance to projector
l
Projector to pen tray
l
Interactive whiteboard to pen tray
l
Audio system to projector
l
Appliance power supply to power outlet
l
Projector to power outlet
l
Room computer to ACP
l
SMART GoWire cable to SBX800 CAT5-XT USB extender (if you're using a room computer)
l
SMART GoWire cable to laptop (if you're using a laptop)
l
Locking the pen tray to your interactive
whiteboard
To learn how to lock the pen tray to your interactive whiteboard, see the SMART Board 800 series
interactive whiteboard user's guide (smarttech.com/kb/144817).
11
