EUROCOM 8880 Dream Machine User Manual page 185

Upgrading The Computer
Figure 7 - 9
7
HDD Removal
7 - 12 Upgrading the Hard Disk in Bay Two
Once you have removed the existing assembly you may then install
the new hard disk in its place.
1. Remove screws "1 - 4", and disconnect cable "5".
2. Take the HDD assembly "6" out of the case.
3. Remove screws "7 - 10" from the HDD assembly (note the ori-
entation of the disk within the assembly brackets).
4. Install the new disk by replacing screws "7 - 10", then reversing
the remainder of the removal process.
1 2
4 3
5
7
8
10
9
6
