Removing And Replacing The Battery - EUROCOM 8880 Dream Machine User Manual

Removing and Replacing the Battery

For the most part you will not need to remove your battery. If you
follow the tips given to manage and extend your battery life on the
preceding pages your battery should last a long time. However there
may be times when you are required to remove, swap or replace the
battery. In these cases please follow these instructions:
1. Shut the computer down and turn it over.
2. Remove screws "1- 4" in Figure 3 - 13.
3. Apply gentle pressure at point "5" to push the battery up and
out of the computer.
1 2 3
4. Slide the new battery in and carefully push it down, then
replace screws "1 - 4" to secure the battery in place.
5
4
Removing and Replacing the Battery 3 - 25
Battery Release
1
Advanced Controls
Figure 3 - 13
3
