6 Maintaining Your System
Do not remove the PC card. The card automatically converts to a
7
backup/restore and remote access card. If you removed other PC cards,
PVM or ASA/DXD, for example, power down the system and reinstall the
PC cards after the upgrade is complete.
If you have a 2-slot carrier or a stand-alone configuration, you are finished
8
with this procedure. If you have a 5-slot carrier, continue with Step 9.
Make sure all modules are seated properly.
9
Perform the following steps to replace the cover for the 5-slot carrier:
10
Position the carrier cover over the modules so that the openings on the
a
top of the carrier cover align correctly with the tabs at the top of the
installed 5-slot carrier and modules.
Rotate the carrier cover into position so that it aligns correctly with the
b
thumb screw opening on the bottom of the carrier.
Tighten the thumb screw. To ensure proper alignment and safe
c
operation, tighten the thumb screw securely.
