Button Locations

When you program from a PARTNER telephone at extension 10 or 11, the button
you press on the telephone at the programming extension may be in a different
location on the telephone being programmed. The following figure shows the
relative location of buttons on each PARTNER telephone.
For example, the button labeled E on the PARTNER-34D telephone in the figure
is in the bottom row. The equivalent button on the PARTNER-18D telephone is in
the leftmost position of the second row from the bottom. If your system has a mix
of PARTNER and MLS telephones, see Appendix D of the PARTNER Advanced
Communications System Release 7.0 Installation, Programming and Use guide
for information about programming from a PARTNER to an MLS telephone or
from an MLS to a PARTNER telephone.
