Initializing the System

Before you initialize the system, you may insert any of the supported PC cards:
Backup/Restore card, Automatic System Answer/Direct Extension Dial
(ASA/DXD) card, PARTNER Voice Messaging Basics card, and PARTNER
Remote Access PC Card.
You must power down the system before you insert or remove a PC
Card.
Follow these steps to initialize a system:
If you have a PC Card, perform the following steps:
1
If your PC Card comes with a write-protect tab, verify that the
a
write-protect tab on the PC Card is not in the write-protected position. If it
is, use a paperclip or another pointed object to push the write-protect tab
on the end of the PC Card upward to the nonprotected position.
To insert the PC Card, hold it with the label facing to the right, and slide it
b
gently into one of the PC Card slots on the processor module. When
inserted properly, the PC Card projects about 1-5/8" (4 cm) from the
module.
If you have a 5-slot carrier, make sure the carrier's On/Off switch is at the
2
Off ("O") position.
Press the power cord firmly into the power jack on the carrier or the
3
stand-alone processor module until the cord locks into place.
Plug the other end of the power cord into a properly grounded three-prong
4
wall outlet that is not controlled by a switch.
If you have a 5-slot carrier, move the On/Off switch to the On ("—") position.
5
CAUTION:
The power cord should hang straight down from the connector for the
entire length of the module or carrier. Do not install the power cord at
an angle to the case or with a loop in it.
