Quick Reference Guide
Connecting the Loudspeaker Paging System
Perform the steps in this section if you have a loudspeaker paging system.
Loudspeaker paging systems allow you to broadcast a message over a large
area. The PARTNER system supports all Avaya paging systems, including the
entire PagePac line. The PARTNER system also supports most paging systems
from other manufacturers when the paging systems are connected using a
paging interface device.
If you connect a loudspeaker paging system from another
manufacturer, a paging interface may be required.
Follow these steps to connect a loudspeaker paging system to the PARTNER
system:
Insert the modular plug from the loudspeaker paging system into an
1
available line jack on a PARTNER module. A loudspeaker paging system
can be connected to a line jack on the following PARTNER modules:
• PARTNER ACS R7.0 processor module
• 308EC module
• 400E module, 400EC module
• 200e module
• 206 module, 206E module, 206EC module
• 362EC module
Connecting the Loudspeaker Paging System
2 Installing Your System
25
