2 Installing Your System
Route the cord through the processor module's wire manager.
2
Connect the other end of the cord to the paging system.
3
26
Connecting the Loudspeaker Paging System
• It is recommended that you connect the loudspeaker paging
system to the highest numbered line jack in your PARTNER
system to help prevent any future conflict with your line
assignments. When you connect a loudspeaker paging
system to a line jack on the PARTNER system, that line is
"unavailable." For example, suppose your system has four
lines, and you connect your loudspeaker paging system to
line jack 4. (The lines are connected to Line jack 1, Line jack
2, Line jack 3 and Line jack 5.) When you administer the
lines, the PARTNER system will label these four lines as Line
1, Line 2, Line 3, and Line 5. Line 4 is unavailable.
• If the loudspeaker paging system requires a "dry contact
relay," you must connect the loudspeaker paging system to
line jack 5 on the PARTNER ACS R7.0 processor module.
