This screen allows you to select the protocol for
communicating through the console port, Console or
SLIP, in the Serial Port field. Use SLIP for out-of-band
management. You can also specify the refresh rate in
the Console Timeout field and the desired setting in
the Baud Rate field. Click Apply and then reboot the
Switch for console port settings to take effect.
The default serial port settings are:
Baud Rate=9600
Data Bits=8
Flow Control=X on/X off
Parity=None
Stop Bits=1
The information is described as follows:
Console Timeout
minutes, 45 minutes, or 60 minutes for the desired
refresh setting.
Serial Port The options for the current console
port setting are Console or Slip.
Baud Rate Determines the serial port bit rate that
will be used the next time the Switch is restarted.
Applies only when the serial port is being used for
out-of-band (SLIP) management; it does not apply
when the port is used for the console port. Available
speeds are 2400, 9600, 19,200 and 38,400 bits per second.
The default setting in this Switch version is 9600.
Web-Based Network Management
Gigabit Ethernet Switch User's Guide
Choose Never, 15 minutes, 30
