xStack
Confirmation
VLAN Name
VLAN ID (1-4094)
User Name
Old Password
New Password
Confirmation
VLAN Name
VLAN ID (1-4094)
Click Apply to implement changes made.

WAC Port Settings

Users can view and set port configurations for Web authentication.
To view the following window, click Security > Web Authentication > WAC Port Settings:
To set the WAC on individual ports for the Switch, complete the following fields:
Parameter
From Port
To Port
Aging Time (1-1440)
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
Retype the password entered in the previous field.
Click the button and enter a VLAN Name in this field.
Click the button and enter a VID in this field.
Enter the user name that has been guest-authenticated through this process, to be mapped
to a previously configured VLAN with limited rights.
Enter the previous password in this field.
Enter the new password in this field.
Retype the password entered in the previous field.
Enter the VLAN name of a previously configured VLAN to which a successfully authenticated
Web user will be mapped.
Click the button and enter a VID in this field.
Figure 5 - 48. WAC Port Settings window
Description
Use this drop-down menu to select the beginning port of a range of ports to be enabled as
WAC ports.
Use this drop-down menu to select the ending port of a range of ports to be enabled as WAC
ports.
This parameter specifies the time period during which an authenticated host will remain in the
authenticated state. Enter a value between 0 and 1440 minutes. A value of 0 indicates the
authenticated host will never age out on the port. The default value is 1440 minutes (24
Config WAC User
138
