System Log Host

The Switch can send Syslog messages to up to four designated servers using the System Log Server.
To view the following window, click Configuration > System Log Configuration > System Log Host:
The following parameters may be configured or viewed:
Parameter
Host ID
Host IP Address
UDP Port (514 or
6000-65535)
Severity
Facility
Status
To set the System Log Server configuration, click Apply. To delete an entry from the System Log Host List table, click the
corresponding Delete button next to the entry.

System Severity Settings

The Switch can be configured to allow alerts be logged or sent as a trap to an SNMP agent or both. The level at which the alert
triggers either a log entry or a trap message can be set as well. Use the System Severity Settings window to set the criteria for
alerts. The current settings are displayed below the System Severity Table.
To view the following window, click Configuration > System Severity Settings:
The following parameters may be configured or viewed:
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
Figure 2- 16. System Log Host window
Description
Syslog server settings index (1 to 4).
The Ipv4 address of the Syslog server.
Type the UDP port number used for sending Syslog messages. The default is 514.
This drop-down menu allows you to select the level of messages that will be sent. The
options are Warning, Informational, and All.
Use the drop-down menu to select Local 0, Local 1, Local 2, Local 3, Local 4, Local 5, Local
6, or Local 7.
Choose Enabled or Disabled to activate or deactivate.
Figure 2 - 17. System Severity Settings window
16
