Table 2-5. 230/240 VAC PDU Power and Current
Component
(Note 1)
230/240 VAC PDU
HP NetServer LPr
HP NetServer
Rack Storage/8
HP NetServer
Rack Storage/12
HP Console Switch
Video Monitor
Note 1 For a full list of power ratings, see the rack configuration utilities (for instance,
Rack Assistant) on the HP Web Site.
Note 2 Indicated current ratings are for use in ordering PDU and UPS components and
may not reflect actual measured amounts.
Description of the Recommended 230/240 VAC Configuration
Figure 13 shows a UPS connected to the power mains through an attached
2-
power cord (appropriate cords are supplied for each server automatically). The
UPS has eight IEC 320 receptacles for use with the rack jumper cords. The
E7671A PDU connects to the UPS via a detachable line cord, which connects to
the PDU via a C19 plug. This cord connects to the UPS with a C20 plug. The
230/240 VAC PDU has two IEC 320, C19 and six IEC 320, C13 receptacles for
connecting rack jumper cords. The fan assembly plugs in using one of the C13
receptacles (No fan assembly is required when no doors are used or doors are
both perforated).
40
Connecting and Routing Cables to the HP NetServer LPr
Model Power (W)
E7671A
All models
D4902A
-
J1497A
Varies with model chosen.
Current (A)
Note 2
N/A maximum
16
305 2.8
209 0.9
537 2.3
70 0.2
