Introduction
This document defines a supported cluster using the HP SureStore E Disk Array FC60 and the HP NetServer LH
6000 and Microsoft Cluster Server. This configuration eliminates single points of failure (SPOF), provides
maximum availability, and has been certified by Hewlett-Packard and Microsoft. This guide is prescriptive; it
describes a configuration supported by HP. Any deviance to this configuration can result in an inoperative
cluster or an operating cluster with degraded performance, hidden SPOFs, etc., and therefore will not be
supported by HP. For all supported configurations, refer to the HP SureStore E Disk Array FC60 for Windows
Configuration Guide.
What's Defined in a Cluster
Cluster
Type of SPUs
Number of nodes
Shared Storage
LANs:
Client LAN
Intra-cluster
(Heartbeat) LAN
Power source
System software:
Operating System
HP Sure Store E Disk Array FC60
with
HP NetServer LH 6000
Cluster Configuration Guide
15 May 2000
Cluster
SPUs
Local and Shared Storage
Intra-cluster and Client LANs
Shared Storage Cabling
HP NetServer LH 6000
Each node must be the same model SPU, but may have different clock
speeds, main memory sizes, cache sizes, and number of CPUs (2, 3, 4, 5 or
6).
2
HP SureStore E Disk Array FC60, and a HP D8602A HBA in the server. See
Shared Storage below.
Any that is HP and Microsoft approved. See Client LAN below.
HP D5013A/B with crossover cable. See Intra-cluster LAN below.
Direct from power mains, power conditioner or uninterruptible power
supply (UPS) using any power conditioner or UPS.
Microsoft Windows NT Server 4.0, Enterprise Edition with Service Pack
SP5 or later
1
Advertisement
Related Manuals for HP D7171A - NetServer - LPr
Summary of Contents for HP D7171A - NetServer - LPr
- Page 1 6000 and Microsoft Cluster Server. This configuration eliminates single points of failure (SPOF), provides maximum availability, and has been certified by Hewlett-Packard and Microsoft. This guide is prescriptive; it describes a configuration supported by HP. Any deviance to this configuration can result in an inoperative cluster or an operating cluster with degraded performance, hidden SPOFs, etc., and therefore will not be...
- Page 2 Model HP NetServer LH 6000 Clock speed 550 Mhz No. of CPUs BIOS version 6.0.1 CPU cache 2 MB 2 GB. Must be HP. No. of power supplies Local storage See Local Storage below. Storage Local Controller May Use - Embedded SCSI, NetRAID-1Si or NetRAID-3Si in PCI slot P1, otherwise any controller listed on the HP Tested Products List.
- Page 3 Disk drives: HP 9.1 GB 10,000 RPM Ultra2 LVD SCSI Disk Module A5637A HP 18.2 GB 10,000 RPM Ultra2 LVD SCSI Disk Module A5638A HP 36.4 GB 10,000 RPM Ultra2 LVD SCSI Disk Module A5639A HP 73.4 GB 10,000 RPM Ultra2 LVD SCSI Disk Module A5640A Cable, 2M Ultra SCSI, VHDCI A5641A Cable, 5M Ultra SCSI, VHDCI A5642A Cable, 10M Ultra SCSI, VHDCI A5643A...
-
Page 4: Shared Storage Cabling
Shared Storage Cabling Two hubs used for HA configuration, 2 NT hosts, 1 FC60 HP LH6000 HP LH6000 HP D8602A HBAs. GBIC are required. Optical or Copper Optical or Copper Optical or Copper Optical or Copper D6976A D6976A Hub always requires a GBIC Optical Optical No GBIC required.
