Chapter 2
Table 2-2. PDU Placement Is not Recommended Behind These Units
HP Product Name
HP NetServer LPr
HP NetServer LXr 8000
HP NetServer LXr Pro8
HP NetServer LH 3
HP FiberChannel 30
HP NetServer Rack
Storage/8
HP NetServer Rack
Storage/12
The two types of 208-240VAC PDUs can be used together to meet different
requirements for current and power receptacles. These combinations are detailed
in Chapter 3 of this document under "Wide Ranging PDU Configurations."
How to Position the PDUs
Count the receptacles needed for each unit in the rack, and notice where the
PDUs can be most conveniently located.
NOTE Due to power requirements, each PDU will support fewer LPr
servers than it has receptacles.
Decide whether to orient the PDU vertically or horizontally.
18
Connecting and Routing Cables to the HP NetServer LPr
Can PDU Be Mounted
Behind?
Yes, but horizontal
mounting requires special
rear brackets
Horizontal mounting not
recommended
Neither horizontal nor
vertical mounting possible
Horizontal mounting not
recommended at bottom of
LH 3r
Not feasible
Horizontal mounting not
recommended
Horizontal mounting not
recommended
Reason
Horizontal mounting on
rear columns causes
interference with rear panel
connectors
Interferes with hot-
swappable power supplies
Cannot extend NetServer
satellite for servicing
Interferes with hot-
swappable power supplies
Mechanically conflicts
Interferes with hot-
swappable power supplies
Interferes with hot-
swappable power supplies
and fans
