Chapter 2
Description of the Recommended 200/208 VAC Configuration
Figure 2-12 shows a UPS connected to the power mains through a captive cord
terminated with an L6-20P plug. The UPS has five receptacles for use in the
rack: two NEMA 5-15 (on the right rear) providing 110 VAC, two L6-20R, and
one L6-30R, providing 208VAC. The E7671A PDU connects to the UPS via a
detachable cord with an L6-20P plug. This cord connects to the PDU with an
IEC 320 C19 plug. The 200/208 VAC PDU has two IEC 320, C19 and six IEC
320, C13 receptacles. A second PDU (E7672A) is available, which can be daisy-
chained to the 16-amp unit, providing ten more C13 receptacles. The fan (not
required if perforated doors or no doors are used front and back) plugs into one of
the C13 receptacles on the PDU.
Connecting and Routing Cables to the HP NetServer LPr
37
