Chapter 2
Alternate 100 - 120 VAC Power Configurations
When the 100-120 VAC PDU is used without a UPS in the rack, the PDU needs
one branch circuit with a NEMA 5-20 receptacle.
NOTE PDUs, UPSs, and power cables will vary from those presented
here to meet Japanese standards.
If neither a UPS nor a PDU are used in the 100-120 VAC case, plug the
components directly into NEMA 5-15 receptacles using the line cords supplied.
If you use a wall socket directly without a UPS or PDU, be sure to check power
requirements against the amperage rating of your electrical system. See the
section titled "Site Preparation: Circuit Breakers" earlier in this chapter. If your
electrical system has the capacity to power the components, plug the HP
NetServer LPr, LH 3r, Pro and Rack Storage/8 units into NEMA 5-15 receptacles
using the 90 inch (approximately 230 cm) power cords supplied.
Table 2-3. 100-120 VAC PDU Power and Current
Component
(Note 1)
100-120 VAC PDU
HP NetServer LPr
HP NetServer Rack
Storage/8
HP NetServer Rack
Storage/12
HP Console Switch
Video Monitor
Note 1 For a full list of power ratings, see the rack configuration utilities (for instance,
Rack Assistant) on the HP Web Site.
Note 2 Indicated current ratings are for use in selecting PDU and UPS components and
may not reflect actual measured amounts.
34
Connecting and Routing Cables to the HP NetServer LPr
Model
E7675A
All models
D4902A
-
J1497A
Varies with model chosen.
Power Current (A)
(W) Note 2
N/A maximum 16
305 5.2 ( )
100 V
4.8 ( )
120 V
209 2.1 (100 V)
1.8 (120 V)
537 5.5 (100 V)
4.5 (120 V)
70 0.3
