Chapter 2
Figure 2-24. Insert Screws through Bezel Latch Assembly and Bezel Hinge
6. Insert two screws on the left through the bezel hinge and into the left rack
column, as shown in Figure 2-24. These screws secure the NetServer to
the rack.
Installation
Insert two screws
through the bezel
latch assembly
into the rack.
Insert two screws through
the bezel hinge into the
rack.
33
