Chapter 2
To attach the 68-pin connector, press on the center of the connector strain
relief and press the connector into place, as shown in Figure 2-16. Two
clicks indicates the connector is properly installed.
Figure 2-16. Attach SCSI Cable Connector
3. Connect the SCSI cable's 68-pin connector labeled "To SCSI Mass Storage
Device" to the SCSI connector on the cage's backplane, as shown in Figure 2-17.
Figure 2-17. Attach SCSI Cable Connector to Cage's Backplane
(Shown Oriented for HP NetServer LH 3 or LH 4)
SCSI Connector on Cage's Backplane
Connector Labeled
"To SCSI Mass
Storage Device"
SCSI Cable
Installation
25
