Chapter 5
Figure 5-9. Disk Device Information Property Sheet
Device Information (Figure 5-8 and Figure 5-9) displays the following
information about the currently selected physical device:
Device Information: RAID Controller
The vendor or source of the controller
The controller's product identification (such as FCArray Assistant)
The revision level of the hardware
The bus width (in bits)
Indicates, by Yes/No, if the following parameters are set:
Synch
Soft Reset
Linked
Command Queuing
ANSI Version supported
Transfer speed and bus width (device state)
104
Monitoring
