1. Display the Emulation Settings dialog box, set the Alpha Emulation option to
IBM5250, then click the OK button. The terminal is now in Network Virtual Terminal
mode until a successful host connection is made.
2. Display the IBM 5250 Settings dialog box and select the particular terminal type to
emulate. This also allows you to specify whether the display is treated as monochrome
(green for normal characters, white for intense attribute) or color for attributes. The
terminal types currently supported and their display characteristics are listed below.
Type
5291_1
5292_2
5251_11
3179_2
3196_A1
3180_2
3477_FC
3477_FG
3486_BA
3487_HA
3487_HC
3. Display the New Connection dialog box from the File menu. Select the TCP/IP pro-
tocol from the Type list box, specify the name of the host to which connection is to be
made, then click the OK button.
4. If necessary, enter the appropriate information to establish an IBM host session in the
Network Virtual Terminal mode screen.
5. When an IBM host session has been established, the screen switches out of Network
Virtual Terminal mode and display the IBM 5250 emulation screen.
7-2
Display Rows x Columns
Monochrome 24 x 80
Color 24 x 80
Monochrome 24 x 80
Color 24 x 80 (default)
Monochrome 24 x 80
Monochrome 24 x 80 and 27 x 132
Color 24 x 80 and 27 x 132
Monochrome 24 x 80 and 27 x 132
Monochrome 24 x 80
Monochrome 24 x 80
Color 24 x 80
