The menu options follow several conventions:
• Options that are displayed dimmed are not applicable to the current mode of operation
and cannot be selected. An example of this is the IBM 5250 option in the Settings
menu. This can only be selected when the IBM 5250 emulation is running.
• Options that include an underlined character may be acted upon by pressing the key
bearing that character. For example, pressing the X key while the File menu is dis-
played causes the emulator to shut down.
• Options that are not followed by an ellipsis (...) perform a particular function when
selected. For example, selecting Reset Terminal in the File menu performs a terminal
reset.
• Options that are followed by an ellipsis indicate that a dialog box displays with all the
selections applicable to that option. For example, selecting Emulation... in the Set-
tings menu displays a dialog box in which you can specify various emulation settings.
1. Click the menu option.
2. Method 1: If the option includes an underlined character, press the key bearing that
character. For example, pressing X while the File menu is displayed causes the emula-
tor to shut down.
Method 2: Use the up or down arrow keys to highlight the option required then hit
Return.
