When the terminal is not in WBT mode, this dialog box is displayed by selecting Serial in
the Settings menu, or by clicking the Configure... button in the New Connection dialog
box when the connection type is set to Serial. Note that the port for serial communications
is selected via the New Connection dialog box that is displayed from the File menu.
Factory default: 9600
This specifies the transmit and receive baud rates for the port selected for host communi-
cations.
Factory default: None
This option specifies the parity mode for each transmitted character. If the number of Data
Bits is 8, set this option to None.
Selecting Odd causes an eighth bit to be added with a value of 1 if the previous 7 bits add
up to an even number, and 0 if the previous 7 bits add up to an odd number.
Selecting Even causes an eighth bit to be added with a value of 1 if the previous 7 bits add
up to an odd number, and 0 if the previous 7 bits add up to an even number. Mark parity
sets every eighth bit to 1 and Space parity every bit to 0.
Setup Menus
