The setting of the Use Colours option in the Preferences box determines whether or not a
specific color is assigned to the text attribute. When the Use Colours option is selected,
the color of the screen element can be changed by tapping on the required color block in
the palette of Foreground and/or Background colors. The two palettes enable you to
specify a different color for text (foreground) and text cell (background). The set of 16
colors displayed can be customized using the Colour Palette dialog box that is described
later.
This list box enables you to select the screen element for definition.
The ANSI Palette option allows you to specify which set of eight Foreground and Back-
ground color indices are used when ANSI color escape sequences are received.
Either the upper or lower eight colors in the Foreground and Background palettes can be
selected. The current eight colors are enclosed within a box. To change the current set of
eight, just tap on any color in the set required.
The list box also enables you to select various display options, depending on the current
terminal emulation mode:
Normal UL+BD
Screen FL+BD
Bold (BD) FL+UL
Underline (UL) IV+FL
Flashing (FL) IV+BD
Inverse (IV) IV+UL
When running the IBM 5250 emulation, the list of character attributes is extended to
include the column separator (CS) attribute.
When running the IBM 3270 emulation, the list box allows selection of the following:
• Unprotected Normal
• Unprotected Bold
• Protected Normal
• Protected Bold
• Status BG
The list of attribute options allows you to enable or disable the actual display of attributes
associated with the selected screen element. Text with the bold attribute may be displayed
as such by checking the Font box when the Screen Element is set to one of the bold
options. Note that text display is slower when Font is selected to display characters with
the bold attribute as bold instead of a substitute color.
FL+BD+UL
IV+UL+BD
IV+FL+BD
IV+FL+UL
IV+FL+BD+UL
Setup Menus
4-33
