Settings with the E extension provide support for the following extended attributes:
3270 field attributes, extended highlighting (blink, flash and underscore, but not in
combination), foreground color, and query reply inbound structured fields. These
attributes are also supported by the 3279. Click the OK button to close the dialog box.
3. Select Save Session in the File menu.
4. Display the New Connection dialog box from the File menu. Select the TCP/IP pro-
tocol from the Type list box, specify the name of the host to which connection is to be
made then click the OK button.
5. If necessary, enter the appropriate information to establish an IBM host session in the
Network Virtual Terminal mode screen.
6. When an IBM host session has been established, the screen switches out of Network
Virtual Terminal mode and displays the IBM 3270 emulation screen.
TN3287 printing is supported by setting the IBM Model option in the Emulation Set-
tings dialog box to 3287-1. When a new Telnet connection is made, the display changes to
show a message box that indicates the current printer status.
When printing commences a Print Abort box displays enabling you to cancel the print job.
Note that this stops print data being sent but does not disconnect you from the host.
When the SysReq option in the Telnet Options dialog box is selected, the key mapped
with the SysReq function enables you to toggle the display and keyboard entries between
the host operating system and the application. This enables you to switch to the operating
system and issue a LOGOFF command. When communicating with the operating system
the status line displaying the
6-2
symbol.
