8. Replace the secure USB compartment cover. See
Compartment Cover on page
9. Reconnect any external devices and power cords.
10. Turn on the monitor, the thin client, and any devices you want to test.
11. Load any necessary drivers.
NOTE:
support.html.
12. Reconfigure the thin client, if necessary.
Removing and Replacing the Secure USB Compartment
Cover
The secure USB compartment allows you to install two USB devices in a secure location inside the thin
client. Along with providing a hidden location, the secure USB compartment can be locked by the
optional security cable lock.
CAUTION:
(131° F) in worst case conditions. Make sure the specifications for any device you install in the
compartment indicate the device can tolerate a 55° C (131° F) ambient environment.
NOTE: In addition to following these instructions, follow the detailed instructions that accompany the
accessory you are installing.
Before beginning the installation process, review
for procedures you should follow before and after installing or replacing hardware.

Removing the Secure USB Compartment Cover

Use the following procedure to remove the secure USB compartment cover.
WARNING!
off and the power cord is disconnected from the electrical outlet.
To remove the secure USB compartment cover:
1. Remove the antenna, if one is installed.
2. On rear of the thin client, remove the screw that secures the compartment cover to the unit (1).
3. On the front of the unit, push the compartment cover about 1.27 cm (1/2 inch) toward the back of
the unit (2).
8 Chapter 2 Hardware Changes
8.
You can download select hardware drivers from HP at
The ambient temperature inside of the secure USB compartment can reach up to 55° C
Before removing the secure USB compartment cover, ensure that the thin client is turned
Removing and Replacing the Secure USB
http://www.hp.com/country/us/eng/
General Hardware Installation Sequence on page 7
