USB PlusPower Ports
This card provides one red-colored 24– volt USB+ connector (1) and three teal-colored 12-volt USB+
connectors (2).
Figure 7-25
The 24-volt USB+ connector (1) and 12-volt USB+ connectors (2) are configured differently as a
precaution to prevent connection errors.
Figure 7-26
1.
Prepare the computer for disassembly
2.
Remove the computer cover
82
Chapter 7 Removal and Replacement Procedures — Small Form Factor (SFF) Chassis
USB PlusPower Ports
24-volt USB+ connector and 12–volt USB+ Connectors
(Computer Cover on page
(Preparation for Disassembly on page
64).
61).
ENWW
