9.
Open the slot cover retainer that secures the slot covers by turning the retainer to the side.
Figure 7-20
10.
Remove the expansion slot cover or the existing expansion card.
a.
If you are installing an expansion card in a vacant socket, remove the appropriate expansion
slot cover on the back of the chassis. Pull the slot cover straight out toward the left side of the
chassis.
Figure 7-21
ENWW
Opening the Riser Card Expansion Slot Retainer
Removing a PCI Riser Card Expansion Slot Cover
Expansion Cards
79
