10. Attach the sheet guide to the scanner.
Pinch the knobs on the sheet guide and attach it to the scanner.
⇒
The sheet guide makes a clicking sound when the knobs fix into position.
Make sure that the sheet guide is completely attached. Otherwise, document
ATTENTION
jams or other feeding errors may occur.
11. Close the ADF.
ADF cover
⇒
You should hear the ADF click when it returns to its original position.
12. Turn on the scanner.
Sheet guide
ScanSnap fi-5110EOX2 Operator's Guide
7.3 Replacing the Pick Roller
Handle
Craw
Paper chute cover
7
151
