4. Attach the new Pad ASSY.
Pad ASSY
Make sure that the Pad ASSY is completely attached. Otherwise, document
ATTENTION
jams or other feeding errors may occur.
5. Close the ADF.
ADF cover
⇒
You should hear the ADF click when it returns to its original position.
ScanSnap fi-5110EOX2 Operator's Guide
7.2 Replacing the Pad ASSY
ADF cover
Paper chute cover
7
145
