1.16.1 Power Supply Considerations
The AP440FX motherboard is designed to operate with a switching power supply in the PS/2
form-factor with dual line input capability, remote ON/OFF, forced air cooling, standby voltage
(VSB), and the following electrical characteristics:
•
Power - 200 W maximum peak, 160 W maximum continuous
•
Rise time for power supply - 2 ms to 20 ms
•
Minimum delay from reset to Powergood - 100ms
•
Minimum Powerdown warning - 1 ms
Table 27. DC Voltage
DC Voltage
+3.3 V
+5 V
+5 V SB (standby)
-5 V
+12 V
-12 V
1.17 Regulatory Compliance
This printed circuit assembly complies with the following safety and EMI regulations when
correctly installed in a compatible host system.
1.17.1 Safety
1.17.1.1
UL 1950 - CSA 950-95, 3rd edition, Dated 07-28-95
The Standard for Safety of Information Technology Equipment including Electrical Business
Equipment. (USA & Canada)
1.17.1.2
CSA C22.2 No. 950-93, 3rd Edition
The Standard for Safety of Information Technology Equipment including Electrical Business
Equipment. (Canada)
1.17.1.3
EN 60 950, 2nd Edition, 1992 (with Amendments 1, 2 & 3)
The Standard for Safety of Information Technology Equipment including Electrical Business
Equipment. (European Union)
1.17.1.4
IEC 950, 2nd edition, 1991 (with Amendments 1, 2 & 3)
The Standard for Safety of Information Technology Equipment including Electrical Business
Equipment. (International)
Current Range (amps)
Acceptable Tolerance
Maximum
+5/-3%
14.0
± 5%
18.0
± 5%
0.1
± 10%
0.3
± 5%
6.0
± 10%
0.8
Motherboard Description
Minimum
0.3
1.0
0
0
0
0
39
