Hayward Pro Logic Operation Manual page 26

For a Pool/Spa Setup selection of "Pool Only", "Spa Only" or "Pool and Spa-Std", Heater1 and/or
Heater2 will keep the filter pump running. For "Pool and Spa-Dual", Heater1 will keep the spa filter
running and Heater2 will keep the pool filter running.
Allow Low Speed
This menu only appears if the filter is configured for 2-speed operation. During default operation,
high speed mode is used whenever the heater is on. If Allow Low Speed is enabled, low speed will be
allowed even if the heater is on.
Minimum Speed
This menu only appears if the filter is configured for variable speed operation. This is the minimum
speed the pump will run at when the heater is on. The selection is from Filter Lowest to Filter Highest
speed.
Heater2 is Heatpump
This menu appears in the Heater2 configuration menu if Heater2 is enabled. If set to "Yes", Heater2
will only be allowed to be on if the Air Temperature is > 50°F. Also, two new menus, Spa Heater2
Priority and Pool Heater2 Priority, will appear in the Settings Menu. Refer to the Settings Menu for
more information on these new menus.
Solar Config. Push to access solar options
+ to view/change
Move to previous/next configuration menu
Solar Toggle between Enabled and Disabled (default) Solar
Disabled
Move to next menu item or previous/next configuration menu
if "Solar" is enabled
Toggle between Enabled and Disabled (default) Solar Extend
Solar-Extend
Disabled
Move to next menu item
if "Solar" is enabled
Toggle between Enabled and Disabled (default) Solar Priority
Solar Priority
Disabled
Move to next menu item
if "Solar" is enabled and
"2-speed Filter" is selected
Toggle between Enabled and Disabled (default)
Allow Low Speed
Disabled
Move to next menu item or previous/next configuration menu
Solar
The Solar configuration menu will NOT appear if "Pool and Spa - Dual" has been selected in the Pool/
Spa setup menu. If the solar control logic is "Enabled", several additional steps must be taken to
ensure proper operation of the solar heating system. If the solar is operated by a valve, then a valve
(Valve3 or Valve4) output must be setup for solar logic (page 29). If the solar is operated by a pump,
then one of the AUX relays must be set up for solar logic (page 27). Also, the "solar" temperature
sensor must be installed. This sensor is typically mounted near the collector array and is used to
sense whether sufficient solar heat is available.
If solar is "Enabled", the valve or solar pump relay will turn on when the water temperature is less than
the desired temperature setting AND the solar sensor is hotter than the water by at least 8ºF. The
desired temperature is in the "Settings Menu". If applicable, the homeowner will be prompted to enter
separate pool and spa desired temperature settings. Depending on the position of the pool/spa
suction valve, the proper temperature setting will be used.
Solar Extend
If "Enabled", the filter extend logic keeps the filter pump running beyond the normal turn-off time if
solar heat is still available. When solar heat is no longer available, both the solar valve/pump and filter
pump will turn off simultaneously. Solar extend will NOT cause the filter pump to turn on, it will only
delay the turn off time when solar is operating.
Solar Priority
If both "Solar Control" and "Heater Control" are enabled, the Solar Priority feature will keep the
conventional heater off whenever solar heat is available. This provides the most cost effective way of
heating the pool. When solar heat is not available, the conventional heater will operate normally.
Allow Low Speed
This menu only appears if the pool filter is configured for 2-speed operation. During default operation,
high speed mode is used whenever the solar heater is on. If Allow Low Speed is enabled, low speed
pump operation will be allowed during solar heating except for the first 3 minutes after solar heat turns
on.
23
only if optional ColorLogic Network
Module is detected at power up
ColorLogic Config. Push to activate ColorLogic options
+ to view/change
Move to previous/next configuration menu
ColorLogic Config.
This menu appears if the optional ColorLogic Network Module is installed and detected at power up.
Refer to the AQL-COLOR-MODHV manual for detailed installation and operation instructions.
External Input Toggle between Open and Closed (default)
Active Closed
Move to next menu item or previous/next configuration menu
External Input
The external input device can either be normally open or normally closed. In this menu, select the state
of the external input device when active. For example, if the switch is normally open and closes when
active, set External Input to "Active Closed".
NOTE: If an AQL-COLOR-MODHV ColorLogic Network Module is detected at startup, only the Lights Name menu will appear
under Lights Configuration. Refer to the AQL-COLOR-MODHV manual for more information.
Lights Config. Push to access Lights options
+ to view/change
Move to previous/next configuration menu
Lights Name
Rotates between all available names
Pool Light
Move to next menu item or previous/next configuration menu
Rotates between Manual On/Off (default), Countdown Timer, Low Speed- Filter,
Lights Function
Timeclock, Solar, Low Speed-Spa Filter, Group, Super Chlorinate, and pH Dispense
Manual On/Off
Move to next menu item
for manual on/off, countdown
timer and timeclock functions
Lights Relay
Toggle between Standard (default), Dimmer and VSP
Standard
Move to next menu item or previous/next configuration menu
for all functions except solar, dimmer relay, super chlorinate
pH dispense, low speed, and group
Toggle between Enabled and Disabled (default) Lights Interlock
Lights Interlock
Disable
Move to next menu item
for group function only
Lights Group Rotates between Manual On/Off (default),Countdown Timer and Timeclock
Timer: None(Manual)
Move to next menu item
for group function only
Lights Group
Options available depend on the function that is selected
Filter: Unaffected
Move to previous/next menu item or next configuration menu
for all functions except solar, dimmer relay, super chlorinate
pH dispense, low speed, and group
Toggle between Enabled and Disabled (default)
Lights Ext Input
Disabled
Move to previous/next configuration menu
f or all functions except dimmer relay, super chlorinate
pH dispense, low speed, and group
Toggle between Enabled and Disabled (default) Lights Freeze
Lights Freeze
Disable
Move to previous/next configuration menu
if filter pump is set to variable speed
and the relay type is set to standard
Select Settings Menu (default) or desired pump speed (Filter Lowest to Highest)
Lights Pump Spd
Settings Menu
Move to previous/next configuration menu
Lights Name
The Pro Logic allows you to assign any one of a number of names (e.g. "Pool Light, Spa Light, Deck
Light, etc.) to this control function. Note that other lights may be assigned to other Aux outputs. This
will make the Pro Logic much more user friendly to the homeowner when they want to turn various
lights on or off. A sheet of small name labels is included with the Pro Logic main unit and each remote
display/keypad so that the "Lights" pushbutton can be labeled the same as the name that you have
assigned. At this time it is also a good idea to make sure that the relay in the control box is also labeled
(hand written) with the same name as a help to technicians who may service this system at a later date.
Lights Function
Although designated as the "Lights" output, the function of the lights relay is similar to the Aux
relays. If pool lights are wired to the lights relay, some options including Solar function, Low Speed
of a 2-Speed Filter Pump, Lights Interlock and Lights Freeze Protection are not applicable and should
