Spa Heater2
Adjust the desired priority interval (Never, 1hr, 2hrs, 3hrs ...22hrs, 23hrs, Always)
Priority: 10 hours
Move to previous/next menu item
The spa heater priority setting will only appear if the system has been setup for "spa only" or "pool
and spa"and if priority has been enabled for Spa Heater2. Choose "Never", "Always" or a selectable
time interval. If an interval is selected, only Spa Heater2 will run when there is a call for heat. After the
interval expires, both heaters will be allowed to operate until the desired temperature has been reached.
Pool
Heater2
Adjust the desired priority interval (Never, 1hr, 2hrs, 3hrs ...22hrs, 23hrs, Always)
Priority: Never
Move to previous/next menu item
The pool heater priority setting will only appear if the system has been setup for "pool only" or "pool
and spa"and if priority has been enabled for Pool Heater2. Choose "Never", "Always" or a selectable
time interval. If an interval is selected, only Pool Heater2 will run when there is a call for heat. After the
interval expires, both heaters will be allowed to operate until the desired temperature has been reached.
Spa Solar
Adjust the desired spa temperature (Off, 65°F, 66°F, ...103°F, 104°F, Off)
102°F
Move to previous/next menu item
The spa solar setting will only appear if the system has been setup for "spa only" or "pool and spa"
operation and the solar control is enabled. The solar system will turn on whenever the pool/spa
valves are in the "spa only" position and the filter pump is running and the spa water temperature is
less than the desired temperature setting and solar heat is available.
Pool Solar
Adjust the desired pool temperature (Off, 65°F, 66°F, ...103°F, 104°F, Off)
88°F
Move to previous/next menu item
The pool solar heater setting will only appear if the system has been setup for "pool only" or "pool
and spa" operation and the solar control is enabled. The solar system will turn on whenever the pool/
spa valves are in the "pool only" or "spa spillover" position and the filter pump is running and the
pool water temperature is less than the desired temperature setting and solar heat is available.
only if an output is configured for a variable speed pump
VSP Speed Settings
Push to access Variable Speed Pump Speed Settings
+ to enter
Move to previous/next configuration menu
only if Filter is Variable Speed
Filter Speed 1
Set the desired Filter Speed 1 from the Filter Lowest to the Filter Highest
95%
Move to next menu item
only if Pool and Spa-Dual and Spa Filter is Variable Speed
Spa Filter Speed 1
Set the desired Spa Filter Speed 1 from the Spa Filter Lowest to Spa Filter Highest
95%
Move to next menu item
only if Pool and Spa-Std and Filter is Variable Speed
Spa Speed
50%
Move to next menu item
only if Aux2 is controlled by a variable speed pump
Aux2 Speed
Set the desired Aux2 Speed from 10% to 100%
95%
Move to next menu item
The Filter, Dual Equipment Spa Filter, and up to 6 Lights and Aux outputs can be configured to control
variable speed pumps. These settings allow you to select the desired speed of the variable speed
pump for each output used. The speed can be displayed in % or RPM, whichever is selected in the
Configuration Menu. For the Filter and Dual Equipment Spa Filter, when the output is on, the actual
speed of the pump(s) will be dependent on the minimum and maximum speeds set for that output in the
Configuration Menu.
Turn super chlorinate on or off
Super Chlorinate
Off
Move to previous/next menu item
This display only appears if the chlorinator function is enabled. If an AQL-CHEM is being used, super
chlorinate will not be available if chemical sensing is enabled and ORP is in Auto Sensing (see AQL-
CHEM manual).
9
38
