Installation Manual Addendum
The following information is intended to replace the instructions found in the
240V) Pool Equipment" section on page 12 or 14 of your
Variable Speed Pump, disregard the installation instructions found in the manual and refer to the
information below.
Hayward Variable Speed Pump: Proper installation of a Hayward Variable Speed Pump (VSP) includes high voltage
input wiring, low voltage communication wiring, and menu configuration/settings. This Pool Control can operate up to 2
Hayward TriStar VSPs and 4 EcoStar VSPs. Refer to the diagram below for proper input wiring to the VSP. Wiring from
the 220V breaker must NOT connect through the Filter/Lights/Aux relay.
The following instructions are intended to replace the information found in the "Low Voltage Wiring"
section on page 16 or 18 of your Installation Manual.
in the manual and refer to the information below.
Hayward Variable Speed Pump (VSP) Wiring and Address Setting
Refer to your TriStar or EcoStar manual(s) for proper low voltage communication wiring between the Pool Control and the
Hayward Variable Speed Pump.
A pump address must be configured for each VSP used in the system. This address is unique to the output used on the
control, and is entered in the VSP's configuration menu. Refer to the table below to determine which address to use. Select
the proper address based on which output will be used and the model VSP you are configuring. Once configured, the
output will control the VSP.
Pool Control Output
This is the output that will be used
to control the VSP.
FILTER - all models
AUX1 - all models
Dual Equipment Spa Filter - all models
LIGHTS - all models
A
UX
2 - all models
A
UX
3-A
UX
6 - PS8 & PS16 models
A
UX
7-A
UX
14 - PS16 models
Installation Manual. If using a Hayward
220 VAC input
power to VSP
Disregard the installation instructions found
VSP Address
This is the name that should be selected
under "Set COMM bus address" (EcoStar)
or "*H.Comm ADDR." (TriStar) within the
VSP's Configuration Menu.
"001" - Tristar
"Pool Filter" - EcoStar
"002" - Tristar
"
Aux1 / Spa Filter
" - EcoStar
"Lights Button" - EcoStar only
Aux2-Aux14 - EcoStar only
(use same as Pool Control Output)
"High Voltage (120/
092465 RevA
