Hayward Pro Logic Operation Manual page 19

if AQL-SS-D is connected
Digital Spa Config. Push to access the Digital Spa Side Remote options
+ to view/change
Move to previous/next configuration menu
Select Digital Spa Rotates between all available remotes
A
Move to next menu item
Rotates between System Off, Pool/Spa, Filter, Lights, Heater1, Valve3,
Digital A, Button 1
Valve4, and all available Aux outputs
Pool/Spa
Move to previous/next menu item
Digital A, Setpoint
Rotates between heaters that are enabled
Heater1 Move to previous menu item or next configuration menu
Select Digital Spa
This menu only appears if more than one AQL-SS-D is detected at power up. Select which of the
available remote controls (A, B or C) is to be configured.
Digital A, Button 1
This menu allows the user to map each button of the AQL-SS-D to one of the standard Pro Logic
functions. The default selections are: Button 1 - Pool/Spa, Button 2 - Filter, Button 3 - Lights, Button
4 - Heater1, Button 5 - Valve3, Button 6 - Valve4, Button 7 - Aux1 and Button 8 - Aux2.
Digital A, Setpoint
If more than one heater is installed, select the spa heater you wish to control. If no heaters are
installed, "Heaters Disabled" will be displayed.
Toggle between Enabled (default) and Disabled Remote Menus
Remote Menus
Enabled
Move to previous/next configuration menu
This feature will prevent unauthorized access to the Settings, Timers, and Configuration menus from
any of the Pro Logic's remote display/keypads. When disabled, the remote display/keypads will only
show the default menu and allow on/off control via the pushbuttons. Note that the function of the Pro
Logic's built-in display/keypad is unchanged by this selection. Once disabled, the only way to enable
"Remote Menus" is to use the local display/keypad.
Toggle between 7-day (default) and Weekend/Weekday time options
All Timeclocks
7-day
Move to previous/next configuration menu
This selection affects ALL of the timeclock logic in the Pro Logic. If "7-day" is selected, each
timeclock will have one set of turn-on/turn-off settings that operate every day of the week. If "Weekend/
Weekdays" option is selected then the user can enter one set of turn-on/turn-off times for the weekend
(fixed as Saturday/Sunday) and another set of turn-on/turn-off times for weekdays (Monday through
Friday).
Toggle between 12 hour AM/PM (default) and 24 hour time format options
Time Format
12 hour AM/PM
Move to previous/next configuration menu
Toggle between ºF and PPM (default) and ºC and g/L (Metric) options
Units
ºF and PPM
Move to previous/next configuration menu
if any output is configured as a
variable speed pump
Toggle between % and RPM
VSP Speed
%
Move to previous/next configuration menu
This is the unit of measure for displaying the speed of the variable speed pump. Select % of your
pump's maximum speed or revolutions per minute (RPM).
31
A table of functions and their corresponding control parameters are listed below.
Function
Pool/Spa Unaffected, Pool only, Spa only, or Spillover
Pool Filter Unaffected, Off, On, High, Low, On (Lowest to Highest)
Lights Unaffected, Off, or On
(standard relay)
Lights Unaffected, Off, On (100%, 80%, 60%, 40%, or 20%)
(dimmer relay)
Lights Unaffected, Off or On (10% to 100%)
(VSP relay)
Spa Filter Unaffected, Off, On, High, Low, On (Lowest to Highest)
Aux1-14 Unaffected, Off
(s tandard relay)
Aux1-14 Unaffected, Off, On (100%, 80%, 60%, 40%, or 20%)
(dimmer relay)
Aux1-14 Unaffected, Off or On (10% to 100%)
(VSP relay)
Valve3 Unaffected, Off or On
Valve4 Unaffected, Off or On
Spa Htr1 Set Unaffected, Off, 65º-104ºF
Pool Htr1 Set Unaffected, Off, 65º-104ºF
Spa Htr2 Set Unaffected, Off, 65º-104ºF
Pool Htr2 Set Unaffected, Off, 65º-104ºF
Spa Solar Set Unaffected, Off, 65º-104ºF
Pool Solar Set Unaffected, Off, 65º-104ºF
SuperChlr Unaffected, Off, On
Note that all functions in the table may not be offered. The available functions are dependent on how the Pro Logic
is configured. For example, if the Pro Logic is configured for a single heater, "Heater2" will not be available as an
option in the Group menu. Also, under some circumstances, functions will be displayed but can't be changed.
Note that the function whose menu you are in, will not be displayed as an option and will automatically turn on
when the group is activated. For example, if programming a Group function under the Lights menu, the Lights
function will not be offered as an option and the Lights function will automatically turn on with the group.
The available control parameters vary with each function. All functions offer "Unaffected", which should be
selected if you do not wish to control that particular function within the group. All other parameters will depend on
the particular function selected.
When activating Group functions, be aware that the most recent Group function that you activate will override any
previous Group functions.
Heater Setpoints in Groups
The Pro Logic can be programmed to use alternate heater setpoints (conventional and/or solar) while running
group commands. This allows the heater to be set to a higher or lower temperature than normal, while the group is
activated. When the group stops, the setpoint will return to its normal setting.
Changing the setpoint while the Group is running will make the Group release the alternate setpoint control and
revert back to the normal heater setting. Any changes that are made at that point will affect the normal heater
setting. The next time the Group is activated, the temperature will return to the group setpoint that was originally
programmed in the Configuration Menu. To change the setpoint while the Group is running, go to the Settings menu
and press the +/- button while "Group Control" is displayed. The setpoint will change and be retained as the new
normal heater setpoint.
Control Parameter
or On
16
