Hayward Pro Logic Operation Manual page 21

NOTE: The configuration for Valve3 and Valve4 are identical. However, if Heater2 was enabled, then the Valve4 configuration
will not appear (a single relay is used to implement either the Heater2 function or the Valve4 function--it can not do both). For
PS-16, see aux logic on page 27 for control of Valves7, 8, 9 and 10.
Valve3 Config. Push to access Valve3 options
+ to view/change
Move to previous/next configuration menu
Valve3 Name
Rotates between all available names
Waterfall
Move to next menu item
Rotates between Manual On/Off (default), Countdown Timer,
Valve3 Function
Timeclock, Solar, In-floor Cleaner, Group, and Super Chlorinate
Solar
Move to next menu item
for all functions except solar, group or super chlorinate
Toggle between Enabled and Disabled (default) Valve3 Interlock
Valve3 Interlock
Disabled
Move to next menu item
for group function only
Valve3 Group
Rotates between Manual On/Off (default),Countdown Timer and Timeclock
Timer: None(Manual) Move to next menu item
for group function only
Valve3 Group Options available depend on the function that is selected
Filter: Unaffected
Move to previous/next menu item or next configuration menu
for all functions except solar, group or super chlorinate
Valve3 Ext Input Toggle between Enabled and Disabled (default)
Disabled
Move to previous/next configuration menu
for all functions except group and super chlorinate
Toggle between Enabled and Disabled (default) Valve3 Freeze
Valve3 Freeze
Disabled
Move to previous/next configuration menu
if filter pump is set to variable speed
and the relay type is set to standard
Valve3 Pump Spd Select Settings Menu (default) or desired pump speed (Filter Lowest to Highest)
Settings Menu
Move to previous/next configuration menu
Valve3 Name
The Pro Logic allows you to assign any one of a number of names (e.g. "Cleaner Valve, Waterfall
valve, Solar Valve, etc.) to each of the valve output control function. This will make the Pro Logic
much more user friendly to the homeowner when they want to turn various valves on or off or program
the timeclocks. A sheet of small name labels is included with the Pro Logic main unit and each remote
display/keypad so that the "Valve3" (and "Valve4") pushbutton can be labeled the same as the name
that you have assigned.
Valve3 Function
Manual On/Off (default) – the valve3 relay will alternate between turning on and off when the
VALVE3 button is pressed. There is no automatic control logic. The VALVE3 button can also be used
to turn the valve output on or off.
Countdown Timer – the valve3 relay will turn on when the VALVE3 button is pressed and then will
turn off automatically after a programmed time (see Timers Menu in the Operations Manual). The
VALVE3 button can also be used to turn the output off.
Timeclock – the valve turns on/off at the times set for the valve3 timeclock in the Timers Menu (see
Operations Manual). The valve3 button can also be used to turn the valve output on or off.
Solar – the valve operates when the filter pump is running and solar heat is available and the water is
less than the desired temperature setting. Solar heating must be enabled in the "Solar Config. menu
for proper operation to occur.
In-Floor Cleaner – the valve switches the water returning to the pool between the in-floor cleaner and
the normal return jets which facilitate efficient surface skimming. The valve will operate the in-floor
cleaner for the first half of each clock hour and then switch to the jets/skimming for the last half of the
hour.
Group – the valve operates when the Group function is initiated and shuts off when the Group
29
Chemistry Config. Press to access Chemistry Config. Wizard
Wizard + to enter
Move to previous/next menu item
Chemistry Configuration Wizard
Requires use of the optional AQL-CHEM Sensing Kit. Following the steps of the Chemistry Config.
Wizard will set up the AQL-CHEM to sense ORP and pH levels and, if the chlorination function is
used, can configure the Pro Logic to generate the correct amount of chlorine to properly sanitize the
pool. Refer to the AQL-CHEM manual for more detailed information.
Pool/Spa Config.
Push to access Pool/Spa options
+ to view/change
Move to previous/next configuration menu
Rotates between Pool and Spa-Std
Pool/Spa Setup
Pool Only, and Spa Only options
Pool and Spa-Std
Move to next menu item
if "Pool and Spa-Dual" is selected
Heaters Toggle between Htr1=Spa, Htr2=Pool (default) and Shared Heaters
Htr1=Spa,Htr2=Pool
Move to next menu item
if "Pool and Spa-Std" is selected
Spa - CountDn
Adjust time setting (Manual On/Off, 0:05, 0:10, 0:15..., (default is 4:00))
00:30 Move to next menu item
if "Pool and Spa-Std or Dual" is selected
Spa Spillover Toggle between Enabled and Disabled
Enabled
Move to next menu item or previous/next configuration menu
if "Pool and Spa-Std or Dual" is
selected and if "Spa Spillover" is enabled
Filter Operation
Toggle between Pool Only
Spa Spillover Move to previous/next configuration menu
if "Pool Only" or "Spa Only" is selected
V1=Aux1, V2=Aux2 Toggle between Enabled and Disabled (default)
Disabled
Move to previous/next configuration menu
if "Pool and Spa-Std" is selected
Filter Off Valve Toggle between Enabled
Change: Enabled
Move to previous/next configuration menu
Pool/Spa Setup
If "Pool Only" or "Spa Only" are selected, then the pool/spa valves are not needed and pushing the
POOL/SPA button on the display/keypad will have no effect. If "Pool and Spa-Std" is selected, then
the pool/spa suction and return valve actuators should be connected to the Pro Logic. Pressing the
POOL/SPA button on the display/keypad will allow the homeowner to alternate between pool and spa
operation. If "Pool and Spa-Dual" is selected, then only the Pool/Spa return valve actuator should be
connected to the Pro Logic.
Heaters
This menu will only appear if Pool/Spa setup is set to "Pool and Spa-Dual". This allows the heater(s)
to either be shared between the pool and spa ("Shared" selected) or for Heater1 to be dedicated to the
spa and Heater2 to be dedicated to the pool ("Htr1=Spa, Htr2=Pool" selected).
Spa CountDn
This menu will appear only if Pool/Spa Setup is set to "Pool and Spa-Std". This setting is the time,
after you manually switch the Pool/Spa valves to "Spa Only", until the Pro Logic automatically
returns the valves to their previous positions. It is programmed in increments of 5 minutes, from
"Manual On/Off" (0 minutes) to
Spa Spillover
When spa spillover is "Enabled" and "Pool and Spa-Std", the homeowner will be able to rotate
through "Pool Only" (both suction and return valves switched to pool), "Spa Only" (both suction and
return valves switched to spa) and "Spillover" (suction valve switched to pool and return valve
switched to spa) by successive presses of the "Pool/Spa" button. For "Pool and Spa-Dual", only
"Pool Only" and "Spillover" are available.
(default) , Pool and Spa-Dual,
(default) Spa Spillover
(default) and Spa Spillover options
(default) and Disabled
"21:00" (21 hours).
The filter is forced on during this time period.
18
